SLE5542 Contact Smart Card Detailed Specifications:
1). Card Name: SLE5542 Contact Smart Card
2). Material: PVC/PET/PP
3). Size: 85.5mm x 54mm
4). Thickness: 0.86mm
5). 256bit encryption card, can read data, write data and password, protect data and write password.
6). ISO 7816 compliant organization
7). 256*8 bit EEPROM organization
8). Byte-wise addressing
9). Irreversible byte-wise write protection of lowest 32 address(byte 0-31)
10). 32*1 bit organization of protection memory
11). 2-wire link protocol
12). Answer to reset according to ISO standard 7816-3
13). Programming time 2.5mS per byte for both erasing and writing
14). Minimum of 10000 write/erase cycles
15). Data retention>10 years
16). Programmable security code (PSC)
17). Data write only after correct 3-byte PSC
18). Packaging: 200pcs/box; 10boxes/Carton
19). Samples availability: free samples are available upon request.
20). Payment Terms: T/T, Western Union and Paypal
